OEM 100w Solar Panel Kit 100w Solar Panel Kit Company
Product details of the 100w solar panel kit
Quick Overview
100w solar panel kit is exquisite in craftsmanship. 100w solar panel kit endows with excellent technique and stable quality. With a viewing to effectively guaranteeing quality for 100w solar panel kit, Huatong Yuanhang (Beijing) Technology Development Co., Ltd introduced efficient quality management system.
Product Description
Compared with products in the industry, HT SOLAR's 100w solar panel kit has the outstanding advantages which are mainly reflected in the following aspects.
Product Advantages
① The charge and discharge efficiency is high, and the charge and discharge efficiency can reach more than 90% in the discharge state.
② Lithium iron phosphate battery has high safety performance.
③ The lithium iron phosphate battery has a long cycle life of more than 5,000 times, and the standard charging (5-hour rate) can reach 2,000 times.
④ Good temperature performance.
⑤ Lithium iron phosphate battery has high capacity.
⑥ No memory effect.
⑦ Lightweight lithium iron phosphate battery.
Technical Parameters of LiFePO4 Battery
|
Nominal voltage |
12.8V |
12.8V |
12.8V |
12.8V |
12.8V |
12.8V |
||||
|
Nominal capacity |
12V20AH |
12V30AH |
12V40AH |
12V45AH |
12V50AH |
12V60AH |
||||
|
Charge voltage |
14.6V |
14.6V |
14.6V |
14.6V |
14.6V |
14.6V |
||||
|
Max. charge current |
10A-30A (optional) |
10A-50A (optional) |
||||||||
|
Peak discharge current |
10A-30A (optional) |
10A-50A (optional) |
||||||||
|
Discharge cut-off voltage |
10V |
10V |
10V |
10V |
10V |
10V |
||||
|
Internal resistance |
≤100mΩ |
≤ 100mΩ |
≤ 100mΩ |
≤ 100mΩ |
≤ 100mΩ |
≤ 100mΩ |
||||
|
Weight |
2.5KG |
4.5KG |
4.5KG |
6.5KG |
7.5KG |
8.5KG |
||||
|
Dimensions (mm) (without controller) |
153*98*150 |
153*98*270 |
153*98*270 |
153*98*380 |
153*98*400 |
153*98*520 |
||||
|
Charge temperature |
-0~45℃ (Heating plate is optional) |
|||||||||
|
Discharge temperature |
-40~50℃ |
|||||||||
|
Storage temperature |
-20~40℃ |
|||||||||
|
Protection functions |
Short circuit protection, Overcharge protection, Over-Discharge protection, Overcurrent protection, Temperature protection. |
|||||||||
|
Applications |
Street Light, Monitoring System, Ups, Off-Grid Power System. |
|||||||||
Technical Parameters of LiFePO4 Battery Pack (50AH)
|
Nominal voltage |
51.2V |
|
Nominal capacity |
50AH |
|
Charge voltage |
58.4V |
|
Charge current |
50A |
|
Peak discharge current |
80A |
|
Discharge cut-off voltage |
40V |
|
Weight |
30KG |
|
Dimensions |
245*200*800mm |
|
Charge temperature |
0 ~ 55℃ |
|
Discharge temperature |
-20 ~ 60℃ |
|
Storage temperature |
-20 ~ 40℃ |
|
Protection functions |
Short circuit protection, Overcharge protection, Over-discharge protection, Overcurrent protection, Temperature protection |
Technical Parameters of LiFePO4 Battery Pack (100AH)
|
Nominal voltage |
51.2V |
|
Nominal capacity |
100AH |
|
Charge voltage |
59.2V |
|
Charge current |
50A |
|
Peak discharge current |
50A |
|
Discharge cut-off voltage |
40V |
|
Weight |
40kg |
|
Dimensions |
540-400-150mm |
|
Charge temperature |
0 ~ 45℃ |
|
Discharge temperature |
-40 ~ 50℃ |
|
Storage temperature |
-20 ~ 40℃ |
|
Protection functions |
Short circuit protection, Overcharge protection, Over-discharge protection, Overcurrent protection, Temperature protection |
Company Advantages
Huatong Yuanhang (Beijing) Technology Development Co., Ltd (referred to as HT SOLAR), is a company that mainly manages Solar power system,Solar system Kits,Solar products in the industry. Our company takes 'service-oriented, quality first' as our business philosophy, and our spirit is 'unity, cooperation, innovation and improvement'. During the development, we constantly learn and absorb international advanced management experience. Moreover, we insist on complementing with all parts of society, to create a first-class corporate brand. Our company carries out advanced talent reserve strategy. Therefore, we introduce a large number of outstanding technical and management talents and they contribute to our development. With a focus on customers, HT SOLAR analyzes problems from the perspective of customers and provides comprehensive, professional and excellent solutions.
Welcome everyone to come for consultation.
