ODM Solar Power System Kit Solar Power System Kit Company
Product Advantages
● Efficient power generation
Maximum efficiency 98.5%, smart MPPT algorithm, tracking efficiency as high as 99.99%.
● Strong scalability
Supports multiple machines in parallel and has strong scalability.
● Wide pressure range
MPPT wide voltage range 100V-500V.
● Safe and reliable
IP65 protection level, multiple protection functions, natural heat dissipation and longer life.
● Smart and friendly
Lightweight and easy to install, it supports remote monitoring via computers and mobile phones.
● Strong heat dissipation
The new cooling solution supports full load operation at 45°C.
Product Parameters
0.7-3KW single phase on-grid solar inverter
| Model | KY-1GT-OK7 | KY-1GT-1KO | KY-1GT-1K5 | KY-1GT-2KO | KY-1GT-2K5 | KY-1GT-3KO | |||||
| Efficiency | MPPT efficiency | 99.50% | 99.50% | 99.50% | 99.50% | 99.50% | 99.50% | ||||
| Max. efficiency | 95% | 96% | 96.50% | 96.50% | 96.50% | 96.50% | |||||
| Euro efficiency | 94.00% | 95% | 95.50% | 95.80% | 96.00% | 96.00% | |||||
| PV Input | Max. PV voltage | 500V | 500V | 500V | 500V | 500V | 500V | ||||
| MPPT voltage range | 80V-450V | 80V-450V | 80V-450V | 80V-450V | 80V-450V | 80V-450V | |||||
| Max. input power | 1000W | 1500W | 2000W | 2500W | 3000W | 3500W | |||||
| Start voltage | 80V | 80V | 80V | 80V | 80V | 80V | |||||
| Min. grid voltage | 110V | 110V | 110V | 110V | 110V | 110V | |||||
| Rated input voltage | 360V | 360V | 360V | 360V | 360V | 360V | |||||
| Number of MPPT/PV strings | 1/1 | 1/1 | 1/1 | 1/1 | 1/1 | 1/1 | |||||
| MPPT max. current | 12.5A | 12.5A | 12.5A | 12.5A | 12.5A | 12.5A | |||||
| Short circuit current | 15A | 15A | 15A | 15A | 15A | 15A | |||||
| AC Output | Max. AC power | 700VA | 1000VA | 1500VA | 2000VA | 2500VA | 3000VA | ||||
| Rated AC power | 700W | 1000W | 1500W | 2000W | 2500W | 3000W | |||||
| Rated grid voltage/voltage range | 230V, 1(LN/PE)/160-280V | ||||||||||
| Frequency | 50HZ/60HZ | ||||||||||
| Max. current | 4A | 5A | 6.5A | 9.5A | 12A | 14.5A | |||||
| Power factor | ~1 (0.8leading ~ 0.8lagging, adjustable) | ||||||||||
| THD (@ rated output) | < 3% | ||||||||||
| AC connection | Quick fit | ||||||||||
| Basic parameters | Operating temperature | -25-60℃ (derating above 45℃) | |||||||||
| Relative humidity | 0-95% no condensation | ||||||||||
| Operating altitude | < 4000m (derating to operate at a height exceeding 2000m) | ||||||||||
| Cooling | Natural cooling | ||||||||||
| Noise | < 40dB | ||||||||||
| Display | LCD | ||||||||||
| Communication | RS485 (WIFI/GPRS optional) | ||||||||||
| Weight | 6KG | 6KG | 6KG | 6.5KG | 6.5KG | 6.5KG | |||||
| Dimensions | 252mm*300mm*116mm | ||||||||||
| Installation | Wall mount | ||||||||||
| Protection | IP65 | ||||||||||
| Topology | Transformerless | ||||||||||
| Certification | Safety | IEC62109-1/-2 | |||||||||
| EMC | EN61000-1/-2/-3, IEC61000 | ||||||||||
| Grid connection | AS4777.2, NRSO97-2-1:2017 | ||||||||||
3.6-6KW single phase on-grid solar inverter
| Model | KY-1GT-3K6 | KY-1GT-4K0 | KKY-1GT-4K6 | KY-1GT-5KO | KY-1GT-6KO | |
| Efficiency | MPPT efficiency | 99.90% | 99.90% | 99.90% | 99.90% | 99.90% |
| Max. efficiency | 96% | 96% | 96.50% | 97.00% | 97.00% | |
| Euro efficiency | 95.50% | 96% | 96.00% | 96.50% | 96.50% | |
| PV Input | Max. PV voltage | 550V | 550V | 550V | 550V | 550V |
| MPPT voltage range | 120V-500V | 120V-500V | 120V-500V | 120V-500V | 120V-500V | |
| Max. input poWer | 4400W | 5000W | 5500W | 6000W | 7200W | |
| Start voltage | 120V | 120V | 120V | 120V | 120V | |
| Min. grid voltage | 150V | 150V | 150V | 150V | 150V | |
| Rated input voltage | 360V | 360V | 360V | 360V | 360V | |
| Number of MPPT/PV strings | 2/2 | 2/2 | 2/2 | 2/2 | 2/2 | |
| MPPT max. current | 12.5A | 12.5A | 12.5A | 12.5A | 12.5A | |
| Short circuit current | 15A | 15A | 15A | 15A | 15A | |
| AC Output | Max. AC poWer | 3600VA | 4000VA | 4600VA | 5000VA | 6000VA |
| Rated AC poWer | 3600W | 4000W | 4600W | 5000W | 6000W | |
| Rated grid voltage/voltage range | 230V, 1(LN/PE)/160V-280V | |||||
| Frequency | 50HZ 60HZ | |||||
| Max. current | 16A | 19.1A | 21.7A | 24A | 27.3A | |
| PoWer factor | ~1 (0.8leading ~ 0.8lagging, adjustable) | |||||
| THD (@ rated output) | <3% | |||||
| AC connection | Quick fit | |||||
| Basic parameters | Operating temperature | -25-60℃ (derating above 45℃) | ||||
| Relative humidity | 0-95% no condensation | |||||
| Operating altitude | < 4000m (derating to operate at a height exceeding 2000m) | |||||
| Cooling | Natural cooling | |||||
| Noise | <40dB | |||||
| Display | LCD | |||||
| Communication | RS485 (WIFI/GPRS optional) | |||||
| Weight | 9KG | 9KG | 9.5KG | 10KG | 10KG | |
| Dimensions | 325mm*375mm*129.5mm | |||||
| Installation | Wall mount | |||||
| Protection | IP65 | |||||
| Topology | Transformerless | |||||
| Certification | Safety | IEC62109-1/-2 | ||||
| EMC | EN61000-1/-2/-3, IEC61000 | |||||
| Grid connection | As4777.2, NRSO97-2-1:2017 | |||||
10-20KW three phase on-grid solar inverter
| Model |
KY-3GT-10k0
|
KY-3GT-12k0
|
KY-3GT-15k0
|
KY-3GT-17kO
|
KY-3GT-20kO
|
|||||
| Efficiency | Max. efficiency | 97.80% | 98.20% | 98.30% | 98.43% | 98.50% | ||||
| Euro efficiency | 98.20% | 97.80% | 97.90% | 98% | 98.10% | |||||
| MPPT efficiency | 99.90% | 99.90% | 99.90% | 99.90% | 99.90% | |||||
| DC Side | Max. input strings power (W) | 13000 | 15600 | 19500 | 22100 | 26000 | ||||
| Rated input power (W) | 10300 | 12350 | 15400 | 17500 | 20520 | |||||
| Max. input voltage (V) | 1000 | 1000 | 1000 | 1000 | 1000 | |||||
| Start voltage (V) | 180 | 180 | 180 | 180 | 180 | |||||
| MPPT voltage range (V) | 200- 950 | 200 - 950 | 200- 950 | 200 - 950 | 200- 950 | |||||
| Number of input strings (pcs) | 1+1 | 1+1 | 2+1 | 2+2 | 2+2 | |||||
| Max. input current (A) | 12/12 | 12/12 | 23/12 | 23/23 | 23/23 | |||||
| Max. DC short-circuit current (A) | 15/15 | 15/15 | 28/15 | 28/28 | 28/28 | |||||
| AC Side | Rated output power (W) | 10000 | 12000 | 15000 | 17000 | 20000 | ||||
| Max. output power (VA) | 10000 | 12000 | 15000 | 17000 | 20000 | |||||
| Rated grid voltage/voltage range | 400V(230V)/270V-480V | |||||||||
| Grid type | 3L/N/PE | |||||||||
| Frequency (HZ) | 50HZ/60HZ 45HZ-55HZ/55HZ-65HZ | |||||||||
| Total harmonic distortion (THD) of output current | < 1.5% | |||||||||
| DC component | < 0.5%*In | |||||||||
| Power factor/range | >0.99(0.8leading 0.8lagging, adjustable) | |||||||||
| Protection | DC switch | Integrate (optional) | ||||||||
| Overcurrent protection/ anti-islanding protection | Integrate | |||||||||
| Surge protection | DC Class Ⅱ / AC Class Ⅲ | |||||||||
| DC reverse polarity protection/overvoltage & undervoltage protection | Integrate | |||||||||
| Leakage current protection/insulation protection | Integrate | |||||||||
| Basic parameters | Dimensions (W*D*H) (mm) | 505*200*414 | ||||||||
| Weight | 16KG | 16KG | 17KG | 18KG | 18KG | |||||
| Protection | IP65 | |||||||||
| Installation/cooling | Wall mount/natural convection | Wall mount/natural convection | Wall mount/forced air | Wall mount/forced air | Wall mount/forced air | |||||
| Topology | Transformerless | |||||||||
| No load loss | < 0.5W | |||||||||
| Operating temperature | -30℃-60℃ (derating above 45℃) | |||||||||
| Relative humidity | 0-95% | |||||||||
| Operating altitude | < 3500m (derating to operate at a height exceeding 2000m) | |||||||||
| Display | LCD | |||||||||
| Communication | RS485/WIFI | |||||||||
| AC/DC connection | Quick fit | |||||||||
| Warranty | 5/10 years | |||||||||
| Certification | Safety | IEC62109-1/-2 | ||||||||
| EMC | EN61000-6-1/-2/-3, EC61000-2-2 | |||||||||
| Grid connection | ASNZS 4777.2, NRS 097-2-1:2017, NBT32004-2018 | |||||||||
Company Advantages
· HT SOLAR POWER solar power system kit is made of high quality raw materials that are guaranteed by our reliable suppliers.
· solar power system kit can be easily adjustable to custom-made products.
· This product offers wonderful user experiences.
Company Features
· HT SOLAR POWER now is a globally famous brand which specializes in producing solar power system kit.
· Huatong Yuanhang (Beijing) Technology Development Co., Ltd has fully developed its own strength in developing new solar power system kit.
· We are committed to sustainable development. We work to reduce our demand for energy through conservation and constantly improving the energy efficiency of our equipment.
Application of the Product
solar power system kit is one of the main products of HT SOLAR. With wide application, our product can be applied to different industries and fields. And it is deeply loved and favored by customers.
HT SOLAR insists on providing customers with Solar power system,Solar system Kits,Solar products of high quality and a one-stop solution that's comprehensive and efficient.
