ODM Small Solar Panel Kits HT SOLAR POWER Company
Product details of the small solar panel kits
Product Information
High quality materials Huatong Yuanhang (Beijing) Technology Development Co., Ltd adopted make small solar panel kits pretty durable. On account of multiple advanced technology, small solar panel kits now stands out in this industry. Manufacturing the flawless small solar panel kits is always the development goal of HT SOLAR POWER.
Product Advantages
① The charge and discharge efficiency is high, and the charge and discharge efficiency can reach more than 90% in the discharge state.
② Lithium iron phosphate battery has high safety performance.
③ The lithium iron phosphate battery has a long cycle life of more than 5,000 times, and the standard charging (5-hour rate) can reach 2,000 times.
④ Good temperature performance.
⑤ Lithium iron phosphate battery has high capacity.
⑥ No memory effect.
⑦ Lightweight lithium iron phosphate battery.
Technical Parameters of LiFePO4 Battery
|
Nominal voltage |
12.8V |
12.8V |
12.8V |
12.8V |
12.8V |
12.8V |
||||
|
Nominal capacity |
12V20AH |
12V30AH |
12V40AH |
12V45AH |
12V50AH |
12V60AH |
||||
|
Charge voltage |
14.6V |
14.6V |
14.6V |
14.6V |
14.6V |
14.6V |
||||
|
Max. charge current |
10A-30A (optional) |
10A-50A (optional) |
||||||||
|
Peak discharge current |
10A-30A (optional) |
10A-50A (optional) |
||||||||
|
Discharge cut-off voltage |
10V |
10V |
10V |
10V |
10V |
10V |
||||
|
Internal resistance |
≤100mΩ |
≤ 100mΩ |
≤ 100mΩ |
≤ 100mΩ |
≤ 100mΩ |
≤ 100mΩ |
||||
|
Weight |
2.5KG |
4.5KG |
4.5KG |
6.5KG |
7.5KG |
8.5KG |
||||
|
Dimensions (mm) (without controller) |
153*98*150 |
153*98*270 |
153*98*270 |
153*98*380 |
153*98*400 |
153*98*520 |
||||
|
Charge temperature |
-0~45℃ (Heating plate is optional) |
|||||||||
|
Discharge temperature |
-40~50℃ |
|||||||||
|
Storage temperature |
-20~40℃ |
|||||||||
|
Protection functions |
Short circuit protection, Overcharge protection, Over-Discharge protection, Overcurrent protection, Temperature protection. |
|||||||||
|
Applications |
Street Light, Monitoring System, Ups, Off-Grid Power System. |
|||||||||
Technical Parameters of LiFePO4 Battery Pack (50AH)
|
Nominal voltage |
51.2V |
|
Nominal capacity |
50AH |
|
Charge voltage |
58.4V |
|
Charge current |
50A |
|
Peak discharge current |
80A |
|
Discharge cut-off voltage |
40V |
|
Weight |
30KG |
|
Dimensions |
245*200*800mm |
|
Charge temperature |
0 ~ 55℃ |
|
Discharge temperature |
-20 ~ 60℃ |
|
Storage temperature |
-20 ~ 40℃ |
|
Protection functions |
Short circuit protection, Overcharge protection, Over-discharge protection, Overcurrent protection, Temperature protection |
Technical Parameters of LiFePO4 Battery Pack (100AH)
|
Nominal voltage |
51.2V |
|
Nominal capacity |
100AH |
|
Charge voltage |
59.2V |
|
Charge current |
50A |
|
Peak discharge current |
50A |
|
Discharge cut-off voltage |
40V |
|
Weight |
40kg |
|
Dimensions |
540-400-150mm |
|
Charge temperature |
0 ~ 45℃ |
|
Discharge temperature |
-40 ~ 50℃ |
|
Storage temperature |
-20 ~ 40℃ |
|
Protection functions |
Short circuit protection, Overcharge protection, Over-discharge protection, Overcurrent protection, Temperature protection |
Company Feature
• Our company is provided with natural resources, superior geographical condition, developed information and convenient transportation.
• HT SOLAR's products are sold well in China and are exported to North America, Eastern Europe, and Southeast Asia.
• Customers' needs are the foundation for our company to achieve long-term development. In order to better serve customers and further meet the needs of customers, we have established a comprehensive after-sales service system to solve their problems. We sincerely and patiently provide customers with information consultation, technical training and product maintenance.
• Our company carries out advanced talent reserve strategy. Therefore, we introduce a large number of outstanding technical and management talents and they contribute to our development.
HT SOLAR's Solar power system,Solar system Kits,Solar products are of reliable quality and reasonable price. Feel free to call us for more information.
