Product details of the portable solar power generator
Product Description
HT SOLAR POWER portable solar power generator is produced in fast and accurate flexibility of production methods. The product is inspected to industry standards to ensure it is free of defects. HT SOLAR POWER has been an experienced enterprise that offering the life-time service timely.
Product Advantages
① The charge and discharge efficiency is high, and the charge and discharge efficiency can reach more than 90% in the discharge state.
② Lithium iron phosphate battery has high safety performance.
③ The lithium iron phosphate battery has a long cycle life of more than 5,000 times, and the standard charging (5-hour rate) can reach 2,000 times.
④ Good temperature performance.
⑤ Lithium iron phosphate battery has high capacity.
⑥ No memory effect.
⑦ Lightweight lithium iron phosphate battery.
Technical Parameters of LiFePO4 Battery
|
Nominal voltage |
12.8V |
12.8V |
12.8V |
12.8V |
12.8V |
12.8V |
||||
|
Nominal capacity |
12V20AH |
12V30AH |
12V40AH |
12V45AH |
12V50AH |
12V60AH |
||||
|
Charge voltage |
14.6V |
14.6V |
14.6V |
14.6V |
14.6V |
14.6V |
||||
|
Max. charge current |
10A-30A (optional) |
10A-50A (optional) |
||||||||
|
Peak discharge current |
10A-30A (optional) |
10A-50A (optional) |
||||||||
|
Discharge cut-off voltage |
10V |
10V |
10V |
10V |
10V |
10V |
||||
|
Internal resistance |
≤100mΩ |
≤ 100mΩ |
≤ 100mΩ |
≤ 100mΩ |
≤ 100mΩ |
≤ 100mΩ |
||||
|
Weight |
2.5KG |
4.5KG |
4.5KG |
6.5KG |
7.5KG |
8.5KG |
||||
|
Dimensions (mm) (without controller) |
153*98*150 |
153*98*270 |
153*98*270 |
153*98*380 |
153*98*400 |
153*98*520 |
||||
|
Charge temperature |
-0~45℃ (Heating plate is optional) |
|||||||||
|
Discharge temperature |
-40~50℃ |
|||||||||
|
Storage temperature |
-20~40℃ |
|||||||||
|
Protection functions |
Short circuit protection, Overcharge protection, Over-Discharge protection, Overcurrent protection, Temperature protection. |
|||||||||
|
Applications |
Street Light, Monitoring System, Ups, Off-Grid Power System. |
|||||||||
Technical Parameters of LiFePO4 Battery Pack (50AH)
|
Nominal voltage |
51.2V |
|
Nominal capacity |
50AH |
|
Charge voltage |
58.4V |
|
Charge current |
50A |
|
Peak discharge current |
80A |
|
Discharge cut-off voltage |
40V |
|
Weight |
30KG |
|
Dimensions |
245*200*800mm |
|
Charge temperature |
0 ~ 55℃ |
|
Discharge temperature |
-20 ~ 60℃ |
|
Storage temperature |
-20 ~ 40℃ |
|
Protection functions |
Short circuit protection, Overcharge protection, Over-discharge protection, Overcurrent protection, Temperature protection |
Technical Parameters of LiFePO4 Battery Pack (100AH)
|
Nominal voltage |
51.2V |
|
Nominal capacity |
100AH |
|
Charge voltage |
59.2V |
|
Charge current |
50A |
|
Peak discharge current |
50A |
|
Discharge cut-off voltage |
40V |
|
Weight |
40kg |
|
Dimensions |
540-400-150mm |
|
Charge temperature |
0 ~ 45℃ |
|
Discharge temperature |
-40 ~ 50℃ |
|
Storage temperature |
-20 ~ 40℃ |
|
Protection functions |
Short circuit protection, Overcharge protection, Over-discharge protection, Overcurrent protection, Temperature protection |
Company Advantage
• The superior location and traffic convenience lay a good foundation for HT SOLAR's development.
• Founded in HT SOLAR developed the business based on large-scale production after years of laborious exploration.
• HT SOLAR's Solar power system,Solar system Kits,Solar products enjoy a good reputation at home and abroad. They are not only widely sold in the domestic market, but also exported to Europe, America, Southeast Asia, Asia, and other countries and regions.
• HT SOLAR thinks highly of talents cultivation. At present, we have a group of employees who effective guarantees the long-term development of our company. They are excellent, professional, dedicated and strict.
Thanks for your interest in HT SOLAR's Solar power system,Solar system Kits,Solar products. If you are interested in our products, please feel free to contact us to place orders. You can enjoy discounts on your first purchase!
