ODM Portable Power Station with Solar Panel Manufacturer
Product details of the portable power station with solar panel
Product Description
HT SOLAR POWER portable power station with solar panel is manufactured using quality proven materials. The product is highly acknowledged among customers for its good durability and lasting performance. HT SOLAR POWER insists on providing customers with the best portable power station with solar panel products and services.
Product Advantages
① The charge and discharge efficiency is high, and the charge and discharge efficiency can reach more than 90% in the discharge state.
② Lithium iron phosphate battery has high safety performance.
③ The lithium iron phosphate battery has a long cycle life of more than 5,000 times, and the standard charging (5-hour rate) can reach 2,000 times.
④ Good temperature performance.
⑤ Lithium iron phosphate battery has high capacity.
⑥ No memory effect.
⑦ Lightweight lithium iron phosphate battery.
Technical Parameters of LiFePO4 Battery
|
Nominal voltage |
12.8V |
12.8V |
12.8V |
12.8V |
12.8V |
12.8V |
||||
|
Nominal capacity |
12V20AH |
12V30AH |
12V40AH |
12V45AH |
12V50AH |
12V60AH |
||||
|
Charge voltage |
14.6V |
14.6V |
14.6V |
14.6V |
14.6V |
14.6V |
||||
|
Max. charge current |
10A-30A (optional) |
10A-50A (optional) |
||||||||
|
Peak discharge current |
10A-30A (optional) |
10A-50A (optional) |
||||||||
|
Discharge cut-off voltage |
10V |
10V |
10V |
10V |
10V |
10V |
||||
|
Internal resistance |
≤100mΩ |
≤ 100mΩ |
≤ 100mΩ |
≤ 100mΩ |
≤ 100mΩ |
≤ 100mΩ |
||||
|
Weight |
2.5KG |
4.5KG |
4.5KG |
6.5KG |
7.5KG |
8.5KG |
||||
|
Dimensions (mm) (without controller) |
153*98*150 |
153*98*270 |
153*98*270 |
153*98*380 |
153*98*400 |
153*98*520 |
||||
|
Charge temperature |
-0~45℃ (Heating plate is optional) |
|||||||||
|
Discharge temperature |
-40~50℃ |
|||||||||
|
Storage temperature |
-20~40℃ |
|||||||||
|
Protection functions |
Short circuit protection, Overcharge protection, Over-Discharge protection, Overcurrent protection, Temperature protection. |
|||||||||
|
Applications |
Street Light, Monitoring System, Ups, Off-Grid Power System. |
|||||||||
Technical Parameters of LiFePO4 Battery Pack (50AH)
|
Nominal voltage |
51.2V |
|
Nominal capacity |
50AH |
|
Charge voltage |
58.4V |
|
Charge current |
50A |
|
Peak discharge current |
80A |
|
Discharge cut-off voltage |
40V |
|
Weight |
30KG |
|
Dimensions |
245*200*800mm |
|
Charge temperature |
0 ~ 55℃ |
|
Discharge temperature |
-20 ~ 60℃ |
|
Storage temperature |
-20 ~ 40℃ |
|
Protection functions |
Short circuit protection, Overcharge protection, Over-discharge protection, Overcurrent protection, Temperature protection |
Technical Parameters of LiFePO4 Battery Pack (100AH)
|
Nominal voltage |
51.2V |
|
Nominal capacity |
100AH |
|
Charge voltage |
59.2V |
|
Charge current |
50A |
|
Peak discharge current |
50A |
|
Discharge cut-off voltage |
40V |
|
Weight |
40kg |
|
Dimensions |
540-400-150mm |
|
Charge temperature |
0 ~ 45℃ |
|
Discharge temperature |
-40 ~ 50℃ |
|
Storage temperature |
-20 ~ 40℃ |
|
Protection functions |
Short circuit protection, Overcharge protection, Over-discharge protection, Overcurrent protection, Temperature protection |
Company Advantage
• HT SOLAR's business covers many cities across the country, and the sales network is expanding year by year. After continuous development, we are currently exploring overseas markets.
• Since the inception in HT SOLAR has been dedicated to the R&D and production of Solar power system,Solar system Kits,Solar products for years.
• HT SOLAR is located in an elegant environment with traffic convenience.
Welcome to HT SOLAR. Thanks for your trust and support. If you have any questions, please feel free to consult us. We are very glad to be at your service!
