Home Solar System Kit by HT SOLAR POWER
Product details of the home solar system kit
Product Description
The entire production process of HT SOLAR POWER home solar system kit strictly follows the international norms. Through the whole process of strict quality inspection, we ensure product quality to meet industry standards. The product has been recognized in the industry for its integrity and strength.
Product Advantages
① The charge and discharge efficiency is high, and the charge and discharge efficiency can reach more than 90% in the discharge state.
② Lithium iron phosphate battery has high safety performance.
③ The lithium iron phosphate battery has a long cycle life of more than 5,000 times, and the standard charging (5-hour rate) can reach 2,000 times.
④ Good temperature performance.
⑤ Lithium iron phosphate battery has high capacity.
⑥ No memory effect.
⑦ Lightweight lithium iron phosphate battery.
Technical Parameters of LiFePO4 Battery
|
Nominal voltage |
12.8V |
12.8V |
12.8V |
12.8V |
12.8V |
12.8V |
||||
|
Nominal capacity |
12V20AH |
12V30AH |
12V40AH |
12V45AH |
12V50AH |
12V60AH |
||||
|
Charge voltage |
14.6V |
14.6V |
14.6V |
14.6V |
14.6V |
14.6V |
||||
|
Max. charge current |
10A-30A (optional) |
10A-50A (optional) |
||||||||
|
Peak discharge current |
10A-30A (optional) |
10A-50A (optional) |
||||||||
|
Discharge cut-off voltage |
10V |
10V |
10V |
10V |
10V |
10V |
||||
|
Internal resistance |
≤100mΩ |
≤ 100mΩ |
≤ 100mΩ |
≤ 100mΩ |
≤ 100mΩ |
≤ 100mΩ |
||||
|
Weight |
2.5KG |
4.5KG |
4.5KG |
6.5KG |
7.5KG |
8.5KG |
||||
|
Dimensions (mm) (without controller) |
153*98*150 |
153*98*270 |
153*98*270 |
153*98*380 |
153*98*400 |
153*98*520 |
||||
|
Charge temperature |
-0~45℃ (Heating plate is optional) |
|||||||||
|
Discharge temperature |
-40~50℃ |
|||||||||
|
Storage temperature |
-20~40℃ |
|||||||||
|
Protection functions |
Short circuit protection, Overcharge protection, Over-Discharge protection, Overcurrent protection, Temperature protection. |
|||||||||
|
Applications |
Street Light, Monitoring System, Ups, Off-Grid Power System. |
|||||||||
Technical Parameters of LiFePO4 Battery Pack (50AH)
|
Nominal voltage |
51.2V |
|
Nominal capacity |
50AH |
|
Charge voltage |
58.4V |
|
Charge current |
50A |
|
Peak discharge current |
80A |
|
Discharge cut-off voltage |
40V |
|
Weight |
30KG |
|
Dimensions |
245*200*800mm |
|
Charge temperature |
0 ~ 55℃ |
|
Discharge temperature |
-20 ~ 60℃ |
|
Storage temperature |
-20 ~ 40℃ |
|
Protection functions |
Short circuit protection, Overcharge protection, Over-discharge protection, Overcurrent protection, Temperature protection |
Technical Parameters of LiFePO4 Battery Pack (100AH)
|
Nominal voltage |
51.2V |
|
Nominal capacity |
100AH |
|
Charge voltage |
59.2V |
|
Charge current |
50A |
|
Peak discharge current |
50A |
|
Discharge cut-off voltage |
40V |
|
Weight |
40kg |
|
Dimensions |
540-400-150mm |
|
Charge temperature |
0 ~ 45℃ |
|
Discharge temperature |
-40 ~ 50℃ |
|
Storage temperature |
-20 ~ 40℃ |
|
Protection functions |
Short circuit protection, Overcharge protection, Over-discharge protection, Overcurrent protection, Temperature protection |
Company Advantage
• Our company has gathered a group of professional technical R&D personnel to provide safe and reliable production technology. With a focus on innovation, we keep up with the times and strive to solve various problems in the procedure of production.
• Under years of rapid development, HT SOLAR has greatly enhanced the comprehensive strength. We have been equipped with a strong technical force and superb production technology.
• HT SOLAR possesses advantageous geographical position transportation here is convenient for the direct buses and nearby subways.
There is always a right fashion accessory for you. Please contact us to order!
