Best Solar Generator HT SOLAR POWER Manufacture
Product details of the best solar generator
Quick Overview
HT SOLAR POWER best solar generator is designed with a distinctive style. The product has gone through the stringent quality check under the supervision of qualified professionals to ensure premium quality. Huatong Yuanhang (Beijing) Technology Development Co., Ltd's service team has outstanding analytical and communication skills.
Product Information
To better learn about best solar generator, HT SOLAR will provide detailed pictures and detailed information in the following section for your reference.
Product Advantages
● Efficient power generation
Maximum efficiency 98.5%, smart MPPT algorithm, tracking efficiency as high as 99.99%.
● Strong scalability
Supports multiple machines in parallel and has strong scalability.
● Wide pressure range
MPPT wide voltage range 100V-500V.
● Safe and reliable
IP65 protection level, multiple protection functions, natural heat dissipation and longer life.
● Smart and friendly
Lightweight and easy to install, it supports remote monitoring via computers and mobile phones.
● Strong heat dissipation
The new cooling solution supports full load operation at 45°C.
Product Parameters
0.7-3KW single phase on-grid solar inverter
| Model | KY-1GT-OK7 | KY-1GT-1KO | KY-1GT-1K5 | KY-1GT-2KO | KY-1GT-2K5 | KY-1GT-3KO | |||||
| Efficiency | MPPT efficiency | 99.50% | 99.50% | 99.50% | 99.50% | 99.50% | 99.50% | ||||
| Max. efficiency | 95% | 96% | 96.50% | 96.50% | 96.50% | 96.50% | |||||
| Euro efficiency | 94.00% | 95% | 95.50% | 95.80% | 96.00% | 96.00% | |||||
| PV Input | Max. PV voltage | 500V | 500V | 500V | 500V | 500V | 500V | ||||
| MPPT voltage range | 80V-450V | 80V-450V | 80V-450V | 80V-450V | 80V-450V | 80V-450V | |||||
| Max. input power | 1000W | 1500W | 2000W | 2500W | 3000W | 3500W | |||||
| Start voltage | 80V | 80V | 80V | 80V | 80V | 80V | |||||
| Min. grid voltage | 110V | 110V | 110V | 110V | 110V | 110V | |||||
| Rated input voltage | 360V | 360V | 360V | 360V | 360V | 360V | |||||
| Number of MPPT/PV strings | 1/1 | 1/1 | 1/1 | 1/1 | 1/1 | 1/1 | |||||
| MPPT max. current | 12.5A | 12.5A | 12.5A | 12.5A | 12.5A | 12.5A | |||||
| Short circuit current | 15A | 15A | 15A | 15A | 15A | 15A | |||||
| AC Output | Max. AC power | 700VA | 1000VA | 1500VA | 2000VA | 2500VA | 3000VA | ||||
| Rated AC power | 700W | 1000W | 1500W | 2000W | 2500W | 3000W | |||||
| Rated grid voltage/voltage range | 230V, 1(LN/PE)/160-280V | ||||||||||
| Frequency | 50HZ/60HZ | ||||||||||
| Max. current | 4A | 5A | 6.5A | 9.5A | 12A | 14.5A | |||||
| Power factor | ~1 (0.8leading ~ 0.8lagging, adjustable) | ||||||||||
| THD (@ rated output) | < 3% | ||||||||||
| AC connection | Quick fit | ||||||||||
| Basic parameters | Operating temperature | -25-60℃ (derating above 45℃) | |||||||||
| Relative humidity | 0-95% no condensation | ||||||||||
| Operating altitude | < 4000m (derating to operate at a height exceeding 2000m) | ||||||||||
| Cooling | Natural cooling | ||||||||||
| Noise | < 40dB | ||||||||||
| Display | LCD | ||||||||||
| Communication | RS485 (WIFI/GPRS optional) | ||||||||||
| Weight | 6KG | 6KG | 6KG | 6.5KG | 6.5KG | 6.5KG | |||||
| Dimensions | 252mm*300mm*116mm | ||||||||||
| Installation | Wall mount | ||||||||||
| Protection | IP65 | ||||||||||
| Topology | Transformerless | ||||||||||
| Certification | Safety | IEC62109-1/-2 | |||||||||
| EMC | EN61000-1/-2/-3, IEC61000 | ||||||||||
| Grid connection | AS4777.2, NRSO97-2-1:2017 | ||||||||||
3.6-6KW single phase on-grid solar inverter
| Model | KY-1GT-3K6 | KY-1GT-4K0 | KKY-1GT-4K6 | KY-1GT-5KO | KY-1GT-6KO | |
| Efficiency | MPPT efficiency | 99.90% | 99.90% | 99.90% | 99.90% | 99.90% |
| Max. efficiency | 96% | 96% | 96.50% | 97.00% | 97.00% | |
| Euro efficiency | 95.50% | 96% | 96.00% | 96.50% | 96.50% | |
| PV Input | Max. PV voltage | 550V | 550V | 550V | 550V | 550V |
| MPPT voltage range | 120V-500V | 120V-500V | 120V-500V | 120V-500V | 120V-500V | |
| Max. input poWer | 4400W | 5000W | 5500W | 6000W | 7200W | |
| Start voltage | 120V | 120V | 120V | 120V | 120V | |
| Min. grid voltage | 150V | 150V | 150V | 150V | 150V | |
| Rated input voltage | 360V | 360V | 360V | 360V | 360V | |
| Number of MPPT/PV strings | 2/2 | 2/2 | 2/2 | 2/2 | 2/2 | |
| MPPT max. current | 12.5A | 12.5A | 12.5A | 12.5A | 12.5A | |
| Short circuit current | 15A | 15A | 15A | 15A | 15A | |
| AC Output | Max. AC poWer | 3600VA | 4000VA | 4600VA | 5000VA | 6000VA |
| Rated AC poWer | 3600W | 4000W | 4600W | 5000W | 6000W | |
| Rated grid voltage/voltage range | 230V, 1(LN/PE)/160V-280V | |||||
| Frequency | 50HZ 60HZ | |||||
| Max. current | 16A | 19.1A | 21.7A | 24A | 27.3A | |
| PoWer factor | ~1 (0.8leading ~ 0.8lagging, adjustable) | |||||
| THD (@ rated output) | <3% | |||||
| AC connection | Quick fit | |||||
| Basic parameters | Operating temperature | -25-60℃ (derating above 45℃) | ||||
| Relative humidity | 0-95% no condensation | |||||
| Operating altitude | < 4000m (derating to operate at a height exceeding 2000m) | |||||
| Cooling | Natural cooling | |||||
| Noise | <40dB | |||||
| Display | LCD | |||||
| Communication | RS485 (WIFI/GPRS optional) | |||||
| Weight | 9KG | 9KG | 9.5KG | 10KG | 10KG | |
| Dimensions | 325mm*375mm*129.5mm | |||||
| Installation | Wall mount | |||||
| Protection | IP65 | |||||
| Topology | Transformerless | |||||
| Certification | Safety | IEC62109-1/-2 | ||||
| EMC | EN61000-1/-2/-3, IEC61000 | |||||
| Grid connection | As4777.2, NRSO97-2-1:2017 | |||||
10-20KW three phase on-grid solar inverter
| Model |
KY-3GT-10k0
|
KY-3GT-12k0
|
KY-3GT-15k0
|
KY-3GT-17kO
|
KY-3GT-20kO
|
|||||
| Efficiency | Max. efficiency | 97.80% | 98.20% | 98.30% | 98.43% | 98.50% | ||||
| Euro efficiency | 98.20% | 97.80% | 97.90% | 98% | 98.10% | |||||
| MPPT efficiency | 99.90% | 99.90% | 99.90% | 99.90% | 99.90% | |||||
| DC Side | Max. input strings power (W) | 13000 | 15600 | 19500 | 22100 | 26000 | ||||
| Rated input power (W) | 10300 | 12350 | 15400 | 17500 | 20520 | |||||
| Max. input voltage (V) | 1000 | 1000 | 1000 | 1000 | 1000 | |||||
| Start voltage (V) | 180 | 180 | 180 | 180 | 180 | |||||
| MPPT voltage range (V) | 200- 950 | 200 - 950 | 200- 950 | 200 - 950 | 200- 950 | |||||
| Number of input strings (pcs) | 1+1 | 1+1 | 2+1 | 2+2 | 2+2 | |||||
| Max. input current (A) | 12/12 | 12/12 | 23/12 | 23/23 | 23/23 | |||||
| Max. DC short-circuit current (A) | 15/15 | 15/15 | 28/15 | 28/28 | 28/28 | |||||
| AC Side | Rated output power (W) | 10000 | 12000 | 15000 | 17000 | 20000 | ||||
| Max. output power (VA) | 10000 | 12000 | 15000 | 17000 | 20000 | |||||
| Rated grid voltage/voltage range | 400V(230V)/270V-480V | |||||||||
| Grid type | 3L/N/PE | |||||||||
| Frequency (HZ) | 50HZ/60HZ 45HZ-55HZ/55HZ-65HZ | |||||||||
| Total harmonic distortion (THD) of output current | < 1.5% | |||||||||
| DC component | < 0.5%*In | |||||||||
| Power factor/range | >0.99(0.8leading 0.8lagging, adjustable) | |||||||||
| Protection | DC switch | Integrate (optional) | ||||||||
| Overcurrent protection/ anti-islanding protection | Integrate | |||||||||
| Surge protection | DC Class Ⅱ / AC Class Ⅲ | |||||||||
| DC reverse polarity protection/overvoltage & undervoltage protection | Integrate | |||||||||
| Leakage current protection/insulation protection | Integrate | |||||||||
| Basic parameters | Dimensions (W*D*H) (mm) | 505*200*414 | ||||||||
| Weight | 16KG | 16KG | 17KG | 18KG | 18KG | |||||
| Protection | IP65 | |||||||||
| Installation/cooling | Wall mount/natural convection | Wall mount/natural convection | Wall mount/forced air | Wall mount/forced air | Wall mount/forced air | |||||
| Topology | Transformerless | |||||||||
| No load loss | < 0.5W | |||||||||
| Operating temperature | -30℃-60℃ (derating above 45℃) | |||||||||
| Relative humidity | 0-95% | |||||||||
| Operating altitude | < 3500m (derating to operate at a height exceeding 2000m) | |||||||||
| Display | LCD | |||||||||
| Communication | RS485/WIFI | |||||||||
| AC/DC connection | Quick fit | |||||||||
| Warranty | 5/10 years | |||||||||
| Certification | Safety | IEC62109-1/-2 | ||||||||
| EMC | EN61000-6-1/-2/-3, EC61000-2-2 | |||||||||
| Grid connection | ASNZS 4777.2, NRS 097-2-1:2017, NBT32004-2018 | |||||||||
Company Advantages
Located in bei jing, Huatong Yuanhang (Beijing) Technology Development Co., Ltd is a new type of company. Solar power system,Solar system Kits,Solar products are main products. To pay back to society with the first-class products and service, we will, as always, adhere to the corporate strategy of 'science and technology, talent support, brand driving, and cultural development', the spirit of 'profession, innovation, integrity and responsibility' and the tenet of 'serving customers and benefiting the society'. HT SOLAR has established a professional marketing team with consumer demand as the core. This has promoted market expansion both at home and aboard and has provided a strong guarantee for the constant supply of high-quality products. HT SOLAR has established a professional technical team. They can provide customers with targeted processes and solutions. Based on this, the problems of customers can be better solved.
Our products are of guaranteed quality and tight package. Welcome customers with needs to contact us!
